Description
The Hikvision DS-3E1105P-EI/M(O-STD) is a compact Smart Managed PoE switch designed for IP surveillance, small office networks, and access control systems. It features 4 × 10/100Mbps PoE ports and 1 × 10/100Mbps uplink port, providing reliable connectivity for IP cameras, wireless access points, VoIP phones, and other PoE-enabled devices. With a 45W PoE power budget and support for IEEE 802.3af/at, the switch delivers power and data through a single Ethernet cable, simplifying installation and reducing cabling costs.
The switch includes intelligent Layer 2 management features such as PoE Watchdog, 802.1Q VLAN, STP/RSTP loop prevention, cable diagnostics, and Extend Mode, which supports PoE transmission distances of up to 300 metres for surveillance applications. Built with a durable fanless metal housing and 6kV surge protection, it ensures stable, silent, and reliable operation in offices, retail stores, schools, warehouses, and CCTV installations.
Key Features
- 4 × 10/100Mbps PoE Ethernet Ports
- 1 × 10/100Mbps RJ45 Uplink Port
- 45W Total PoE Power Budget
- IEEE 802.3af/at PoE Support
- Smart Layer 2 Management
- 802.1Q VLAN & QoS Support
- PoE Watchdog for Automatic Device Recovery
- Up to 300m Extended Transmission Mode
- 6kV Surge Protection
- Fanless Metal Housing
